As a leading manufacturer, we provide high-precision, customizable OEM 3D wheel alignment clamp accessories.
Enhance your wheel alignment system's accuracy with our reliable adapters.
A:
This 3D wheel alignment clamp is engineered for professional workshops that demand consistent, repeatable alignment data across a wide range of vehicles. Unlike single-point or three-point clamps, the four-point contact system distributes clamping force evenly across the rim, eliminating flex and preventing measurement drift during critical alignment procedures.
Each alignment clamp is forged from 6061-T6 aluminum and precision CNC-machined to ±0.1mm tolerance. The four contact points are synchronized to engage the rim bead seat simultaneously, ensuring the clamp remains perfectly centered and stable. This design directly addresses the most common cause of inaccurate alignment readings: clamp movement during measurement.
The alignment clamp is compatible with all major wheel alignment machines and wheel alignment system brands, It requires no adaptor rings or special tools for installation, reducing setup time and technician training requirements.
Product name: 3d Electronic Wheel Alignment Clamp for Alignment for 12"-24" rims.
Material:Forged 6061-T6 aluminum,
Planeness tolerance: ±0.1mm
Load capacity: 500 kgs.
Compatibility: Compatible with all brands wheel alignment machines and all alignment systems.
Certificate: ISO 9001:2015 certified factory.
R&D capability: OEM/ODM available.
MOQ: 50 sets. One set include 4pcs clamps
This 3D wheel alignment clamp is designed for the full spectrum of passenger vehicle and light commercial applications. Its four-point contact system is particularly valuable in environments where vehicle types change frequently and setup speed matters.
Passenger Car Service
Fits standard steel and alloy wheels on sedans, hatchbacks, and coupes. The four-point grip prevents damage to delicate alloy finishes while maintaining secure attachment.
SUV and Crossover Alignment
Accommodates larger wheel diameters and heavier wheel assemblies. The 500 kg load rating provides a safety margin for SUVs and crossovers with aftermarket wheels.
Light Truck and Van Applications
Suitable for light commercial vehicles and delivery vans with rim diameters up to 24". The clamp's robust construction handles the increased weight and vibration of commercial use.
High-Volume Tire and Service Centers
The quick-install four-point mechanism reduces setup time by approximately 40% compared to traditional clamps, directly increasing bay throughput.
Request a quote for our 3D wheel alignment clamp:
Your brand is unique, and your components should reflect that. We specialize in providing seamless OEM and ODM manufacturing services for producers of 3D wheel alignment machines. We go beyond standard products to deliver a custom solution that integrates perfectly with your brand identity and technical specifications.
Our collaborative process includes:
Brand Customization: use custom colors, and package the clamps in your boxes for a seamless unboxing experience.
Design Adaptation: Our engineering team can modify clamp geometry, weight, and interface mechanisms to meet the specific requirements of your 3D alignment system.
Prototyping & Validation: We rapidly produce functional prototypes for your testing and approval, ensuring the final product performs flawlessly before mass production.
We become an extension of your manufacturing team, ensuring the 3D wheel alignment clamps you offer are built to your exact standards of quality and performance.
The accuracy of a 3D wheel alignment system is dependent on the stability of the connection to the wheel. Our clamps are engineered with specific features to maximize data integrity and operational efficiency.
Optimized for 3D Targets: The clamp design provides an ultra-stable platform for 3D alignment camera targets, minimizing vibration and ensuring the capture of precise, repeatable measurement data.
Rigid, Lightweight Construction: Manufactured from high-strength aluminum, our clamps offer the perfect balance of minimal weight for technician comfort and maximum rigidity to prevent flex, which is critical for 3D alignment accuracy.
Universal Compatibility: Designed to fit a wide range of rim diameters (13"-24") and types, ensuring your 3D alignment machine can service the broadest possible customer base, from compact cars to light trucks.
Durable, Maintenance-Free Operation: With sealed bearings and a hard-anodized finish, these clamps are built to withstand daily workshop use, reducing warranty claims and maximizing uptime for your customers.
Partner with a wheel alignment manufacturer that understands the precision requirements of modern 3D alignment technology. Contact our OEM team today to discuss your project and request a competitive quotation.
[ Request OEM Pricing Guide ] : Click here to contact our clamp specialist
Q: What rim diameters does this universal four point wheel alignment clamp support?
A: It fits rim diameters from 11" to 24", covering passenger cars, SUVs, light trucks, and vans.
Q: What is the minimum order quantity for OEM orders?
A: Standard MOQ is 100 sets(400pcs). Custom branding and packaging are available from 200 sets(800pcs).
Q: What material is used in the clamp?
A: Forged 6061-T6 aluminum with Type III hard anodized finish for corrosion and wear resistance.
Q: How much does one clamp weigh?
A: Approximately 5 kg per clamp, optimized for technician ergonomics and reduced fatigue.
Q: Can this clamp be used on alloy wheels without causing damage?
A: Yes. The four contact points are designed with protective polymer inserts that prevent scratching or marring of alloy wheel surfaces.
Q: Are you the real manufacturer for wheel alignment clamp?
A:Yes, we are the manufacturer, you can visit us at any time.
Q: Can you do OEM and ODM wheel alignment clamp with different design?
A:Yes, we can. With our 20+ experience focus on alignment accessories field, we can design and produce alignment clamps and turn plates as per your suggestion.
Q:Which aspects of the wheel alignment clamps can you customize?
A:All aspects including shape and colors.
Q: Do you accept small MOQ?
A:Yes, you can place a small trial order to get a better understanding of us.
Q:How long is the delivery time for wheel alignment clamp usually?
A: A mature product will be completed within 20 days.
Q: Are the 3D wheel alignment clamps compatible with all models of the four-wheel alignment machines?
A:Yes, it is compatible for all models of wheel alignment machines.
